110kv Three Circle Voltage-Regulating Power Transformer
| Model NO. | S (FSZ) 9, S (FSZ) 10, S (FSZ) 11 Series |
| Winding Type | Multi-winding Transformer |
| Usage | Power Transformer |
| Shape of Core | Ring |
| Symbol | Yn,Yn0,D11 |
| LV | 35 36.6 38.5 |
| Specification | IEC Standard |
| Origin | Ningbo China |
| Production Capacity | 5000 Sets/Year |
| Cooling Method | Oil-immersed Type Transformer |
| Certification | ISO9001-2000, ISO9001 |
| Frequency Characteristics | Power Frequency |
| Brand | Ville |
| Hv | 110 115 121 |
| Transport Package | The Accessories Packed in Plywood Cases,The Main B |
| Trademark | ville |
| HS Code | 85 |
Product Description
110kV Oil-immersed type power transformer
General :
Adopting advanced and strictly technology, the 110kV's transformer that we develops to produce index all
achieves the advanced standard of international by way of constantly exploring and make perfect. The product
possesses characteristics such as the low loss, low noise and low power in part and the resisted short circuit
ability is strong etc. The product breed is diversified and the model specifications complete.
The transformer product can be installed and use in outdoor or indoor, and it is very ideal equipment in the
distribution network in factory, rural area and city.
Features:
1 Short-circuit capability
The use of advanced computer program for calculating the transformer short-circuit conditions, analysis of the
coil short-circuit conditions in various parts of the force and deformation. Transformer short circuit capacity can
be greatly improved.
2 low loss
Optimization of electromagnetic calculations, using a variety of ways to effectively control the leakage magnetic
shielding to reduce the load loss and to avoid overheating.
High quality cold-rolled silicon steel lattice orientation of high permeability, the use of miter joints STEP step, no
holes are not stacked on the yoke process, reduce the load loss, load current, electromagnetic noise.
3 high mechanical strength
Six-side positioning of the body using methods to meet the transport direction of the acceleration level is not
greater than 0.3G, the vertical direction is not greater than 0.15g.
Technical Data:
| Products Model |
Rated Voltage | Symbol | No-load Loss (W) |
Load Loss (W) |
No-load Current (%) |
Impedance Voltage (%) | |||
| High Voltage (kA) |
Tapping Range |
Low Voltage |
Stepping Up Becomes |
Decompression Becomes |
|||||
| SFSZ10-6300/110 | 110 115 121 ±8×1.25% |
35 36.6 38.5 ±2×2.5% |
6.3 6.6 10.5 11 |
YN, yn0, d11 |
10.5 | 45 | 0.6 | (H)-(M)17.5% (H)-(L)10.5% (M)-(L)6.5% | (H)-(M)10.5% (H)-(L)17.5% (M)-(L)6.5% |
| SFSZ10-8000/110 | 12.5 | 54 | 0.6 | ||||||
| SFSZ10-10000/110 | 14.5 | 63 | 0.6 | ||||||
| SFSZ10-12500/110 | 16.9 | 70 | 0.6 | ||||||
| SFSZ10-16000/110 | 19.4 | 86 | 0.6 | ||||||
| SFSZ10-20000/110 | 22.6 | 102 | 0.6 | ||||||
| SFSZ10-25000/110 | 26.2 | 142 | 0.5 | ||||||
| SFSZ10-31500/110 | 31.7 | 145 | 0.55 | ||||||
| SFSZ10-40000/110 | 35 | 172 | 0.5 | ||||||
| SFSZ10-50000/110 | 37.04 | 207 | 0.46 | ||||||
| SFSZ10-63000/110 | 42.7 | 243 | 0.42 | ||||||
